智能型差压变送器Intelligent pressure transmission
安装使用说明书Installation instructions
京制00000260号System of Beijing no. 00000260
北京瑞普恩德斯豪斯有限公司Beijing Endress+Hauser Ripenss Instrumentation Co.,Ltd

北京市朝阳区三元桥霞光里5号Sanyuanqiao  Xiaguangli No.5 Beijing Chaoyang District
电话Phone
传真Fax
邮编ZIP
第二页
智能压力变速器是德国E+H公司新近推向市场的智能型仪器
Intelligent pressure transmission is Germany E + H company newly brought to the market of intelligent instruments

用于测量流量、液位或差压Used to measure flow, liquid level or differential pressure
PMD230采用陶瓷传感器，PMD235采用扩散硅传感器
PMC and PMP differ in that PMC uses ceramic sensorsand PMP uses diffusion silicon sensors

技术数据technical data
 世联翻译公司完成PMD安装说明书英文翻译
负载特性load characteristic
测量系统组成Measurement system composition
传感器允许最大过程压力the maximum process pressure Sensor allows
外形结构Configuration
普通型电气连接Normal electrical connections
本安型接线框图Intrinsically safe wiring diagram

隔爆型接线和安装应注意explosion proof type connection and installation should pay attention to

本安型安装使用时应注意Intrinsically safe type installation and using should pay attention to

安装方式installation method
安装压力管线installation Pressure pipeline
注意变送器安装位置Pay attention to the position of transmitter installation
安装后通过以下方法调整显示表的方向using the following method to adjust the direction of the display after installation

零点满度调节Zero and full adjustment
标定模式下的显示Calibration Mode display

按键功能（概述）Key functions (overview)
按键设定零点Button to set zero point

按键设定满度Button to set full point
偏压bias voltage
标定Calibration

无显示标定No display calibration
带显示标定Display calibration

阻尼damping
输出功能Output power and energy
设置t和输出功能set T and Output power and energy
流量小于Qmax的8.9%时注意When the flow rate is less than 8.9% of Qmax, please pay attention
按键锁定与解锁button lock and unlock
贮存storage
运输transportation
使用期限service life
产品配套Product Support
技术数据technical data
输出output
线性（正比于差压）或平方根（正比于流量）模拟信号，可开关设定，同时按用户需要叠加通讯信号（协议）协议，前者用VU26OZ手持终端，后者用DXR手持终端
Linear (is proportional to the differential) or square root (Is proportional to the flow) analog signals, can be set in a switch, at the same time according to user needs to overlay communication signal agreement, the former with VU26OZ handheld terminals, the latter with DXR handheld terminal

温度影响temperature influence
零点或满度输出zero or full output
线性度linearity
含迁移后量程range including after change
量程比range ratio
迟滞lag
陶瓷传感器ceramic sensor
扩散硅传感器diffuse silicon sensor
重复性repeatability
陶瓷传感器ceramic sensor

扩散硅传感器diffuse silicon sensor

预热时间preheating time
响应时间response time
长期漂移long term drift
陶瓷传感器ceramic sensor


扩散硅传感器diffuse silicon sensor


输出阻尼output damping
开关调整switch adjustment
手持终端或个人计算机调整Handheld terminal or personal computer adjustment
允许温度allowable temperature
环境温度environment temperature
普通型ordinary type

本安型Intrinsically safe type
隔爆型flame-proof type

介质温度medium temperature

普通型ordinary type

防爆型explosion proof type

工作电压working voltage
普通型ordinary type

防爆型explosion proof type
第三页
残余脉动Residual ripple
在电压容限内，残余脉动不大于In voltage tolerance, residual ripple is not greater than
对于信号无影响has no effect  for the signal
叠加通讯信号overlying Communication signal
协议agreement
振动影响vibration influence
静压影响influence of static pressure
陶瓷传感器ceramic sensor

扩散硅传感器diffuse silicon sensor
防护等级level of protection
防爆标志explosion-proof sign
本安型Intrinsically safe type

隔爆型flame-proof type

本安型应与以下四种安全栅中的任一种组成本安防爆系统Intrinsically safe type should combine with either of the following four kinds of safety barrier to be safety explosion protection system
普通型ordinary type
防爆型explosion proof type

第四页
测量系统组成Measurement system composition
智能差压变送器Intelligent pressure transmission
输出output
LCD显示（差压、流量或液位）、棒图显示或模拟显示（任选件）LCD display,  Bar graph display or pointer analog display(any one)

电源power supply
关闭阀shutoff valve
三阀组或3个分离阀three valves manifold or three separate valve group
第五页
传感器允许最大过程压力Sensor allows the maximum process pressure
扩散硅传感器diffuse silicon sensor
陶瓷传感器ceramic sensor
额定量程The rated range
系统过程压力System pressure
单向one-way
双向Bi-directional
额定量程The rated range
带PVDF涂层过程连接件的PMD230，该数据应改为1MPA   PMD230 fittings with PVDF coating process, the data should be changed to 1 mpa

指高静压传感器the high static pressure sensor
第六页
外形结构Configuration
现场显示器scene display
工作标牌Work sign
安装螺孔Installation screw hole
过程螺孔Process screw hole
电缆密封套cable gland
电缆孔cable hole
第七页
普通型电气连接Normal electrical connections

检测detection
本安型接线框图Intrinsically safe wiring diagram

本安型Intrinsically safe type
安全栅Safety Barrier
危险区danger area
安全区safety area
第八页
防爆型接线和安装应注意Explosion-proof wiring and installation should pay attention to
开盖前务必切断电源Be sure to cut off power supply before open
接线后或显示表调整方向后，应注意将盖旋紧再用盖侧的金属块通过螺钉压紧在盖的边沿上
After wiring or adjusting display direction, pay attention to tighten it and use metal block by screw clamps on the edge of the cove.
隔爆型电源电压Flameproof power supply voltage
隔爆型选用的电缆线外径，必须与密封圈内径相配Flameproof type’s cable diameter must be matched with the sealing ring inside diameter

变送器外壳设有接地端子，用户在安装使用时应可靠接地
Transmitter shell is equipped with grounding terminals. Should be reliable grounding when used in the installation
用户在安装使用和维护产品时应同时遵守GB50058-92和GB3836.15-2000的有关要求
Users shall comply with GB3836.15-2000 and GB50058-920 on request in the installation and maintenance of the products

电缆引入口应配用经防爆认可的Exd C等级的电缆引入装置
Cable introduce mouth should be equipped with Exd C level of the explosion-proof cable entry device

本安型安装使用时注意Intrinsically safe type should pay attention to when installation and using
变送器必须与安全栅配套使用构成本安防爆系统
Transmitter must be used with safety gate to compose intrinsically safe type explosion protection system

夲安系统的接线请同时参阅产品说明书和安全栅使用说明书
intrinsically safe type system wiring should refer to product specifications and safety barrier operation instruction at the same time
本安系统的布线应尽量避免外界电磁干扰的影响，并将电缆分布参数控制在0.06uf和1mH以内
Intrinsically safe type wiring should avoid the influence of outside electromagnetic interference as far as possible, and cable distribution parameters should be controlled within 0.06 uf and 1 mh
安全栅的安装、使用和维护应遵守安全栅使用说明书
Safety barrier installation operation and maintenance shall comply with the safety barrier operating instructions
用户在安装使用和维护产品时务必认真阅读产品安装使用说明书，并严格遵守和的有关要求要求
Please read the product installation instructions, and strictly comply with relevant requirements ofandin the installation operation and maintenance of this product
变送器外壳设有接地端子，用户在安装使用时应可靠接地
Transmitter shell is equipped with grounding terminals, should be reliable grounding when use in the installation
第九页
安装方式installation mode
管架式：采用导管引压，用安装支架装于水平管架或垂直管架上（如图）
Pipe rack type: using catheter to bring pressure, installed in horizontal or vertical piping support with mounting bracket (as shown in the picture)
墙装：采用导管引压，用安装支架固定于墙面（如图）
Wall type: using the pipe to bring pressure, installed to the wall with mounting bracket. (as shown in the picture)
水平管架horizontal pipe rack
垂直管架vertical pipe rack
墙装 wall type
第十页
安装压力管线installation Pressure pipeline
压力管线用于两个测量点和变送器之间的传导压力，安装时注意以下几点
Pressure pipeline is used for pressure conduction between the two measurement point and transmitter.  When installation, pay attention to the following points

用12X1.5mm或略粗的压力管线use 12 x1. 5 mm or slightly wider pressure pipeline
确保其防腐型Ensure its anti-corrosion type
压力管线要尽可能短，勿使遭受机械变形Pressure pipeline should be as short as possible.  Be not subject to make by mechanical deformation
避免死弯Avoid bending世联翻译公司完成PMD安装说明书英文翻译
压力管线至少应有10%的梯度（每米），以避免堵塞pressure pipeline should be at least 10% of the gradient (per meter), in order to avoid clogging
应永久性的安装在测量点上（墙装方式或管家方式），不得随意放置或悬挂
Shall be permanently installed on the measuring point (wall or pipe frame), shall not be arbitrarily placed or suspension

差压测量与介质密度有关，故两压力管线应在相同的温度下，为了取得精确地测量结果，安装时应使两者相互接近，或确保他们与外界隔热，或者将其栓连在一起
Differential pressure measurement is related to medium density, so the two pressure pipeline should be in the same temperature. In order to obtain a precise measurement results, when installation,  should make both close to each other, or make sure they are insulated with the outside world, or  bolt together

注意变送器安装位置Pay attention to the position of transmitter installation
测量气体时，应安装在测量点上方Measuring gas should be installed above the measurement point
测量液体时，应安装在测量点的下面Measuring gas should be installed below the measurement point
测量液位时，必须安装在最低液位以上，测量膜片应被介质完全覆盖
Measuring liquid level, must be installed above the lowest level.  Measuring diaphragm should be  fullyl covered by media.
安装位置应尽可能接近测量点，以缩短压力管线的长度
Installation position should be as close as possible to measure points, so as to shorten the length of pressure piping
安装时应使下列干扰因素缩小到最低程度或授权排除
When installation, the following interfering factors
should be reduced to a minimum or authorized to rule out
振动或机械冲击Vibration and mechanical shock
大的温度变化Big changes in temperature
腐蚀性空气和凝结Corrosive air and condensation
第十一页
安装后可通过以下方法调整显示表的方向
After installation, can use the following method to adjust the direction of the display
调整变送器壳体方向Adjust the transmitter shell direction
松动止动螺钉Loosen lock screw
旋紧止动螺钉Tighten the set screw
最大330度Maximum 330 degrees
打开显示窗盖，显示表可90度一级转动到所需位置
Open the display window cover, display table can turn 90 degrees to the required position
向外推开卡头push the card head out

第十二页
零点满度调节zero and full adjustment
压力与电流显示Pressure and current display
两个例子two examples
标定的测量量程Calibrated measuring range
显示display
第十三页
标定模式下的显示display of the calibration mode
显示压力零点Display the zero pressure
显示压力满度Display the full pressure
传感器例sensor example

零点zero point
满度full point
传感器低限Sensor low limit
传感器高限Sensor high limit
在标定零点和满度期间，条形显示器示出设定的压力量程和传感器测量范围极限
Between the calibrated zero and full point, bar display shows the pressure range and sensor measurement range limit

反向电流输出Reverse current output
第十四页
按键功能（概述）Key functions (overview)
单按键功能Single button function
增加零点数值Increase the zero value
减少零点数值decrease the zero value
增加满度数值Increase the full value
减少满度数值decrease the full value
双按键功能two buttons function
组合方式Combination mode
功能function
标定Calibration
使传感器受到的压力为量程零点make The pressure on the sensor the range  zero
使传感器受到的压力为量程满度make The pressure on the sensor the range full

偏压bias voltage
按两次+z和+s press   twice
使传感器受到的压力登陆为偏压make The pressure on the sensor  bias voltage
按一次+z和+s press    once
显示偏压 display bias voltage
按两次-Z和-S press   twice
消除偏压clear bias voltage
锁定、解锁功能Lock unlock function
和with
锁定测量点（按键操作禁止）Lock the measurement points (button operation is prohibited)
解锁测量点（按键操作允许）unlock the measurement points (button operation is permitted)
第十五页
按键设定零点Button to set zero point
零点显示Zero point display
按+Z或-Z press  or
松开两秒后显示返回正常Loosen for two seconds,  display returns to normal
按键press button
增加零点压力Increase the zero point pressure
按+z两次之后保持至所需值After press the + Z button twice, keep to the required value

减少零点压力decrease the zero point pressure
按-Z两次之后保持至所需值After press the - Z button twice, keep to the required value
第十六页
按键设定满度Button to set full point
满度显示full point display
按+S或-S press or
松开两秒后显示恢复正常after Loosen for  two seconds,  the display returns to normal
按键press button
增加满度压力increase full point pressure
按+S两次后保持至所需值After press the + S button twice, keep to the required value

减少满度压力decrease the full point pressure

按-S两次之后保持至所需值After press the- Z button twice, keep to the required value

第十七页
偏压bias voltage

例for example
这意味着it means
显示的修正display  the revised
例如对于静压柱或安装位置影响的显示修正For example, static pressure column or installation location affect the display of the correction
一侧one side
压力度数Pressure readings
传感压力sensor pressure
偏压bias voltage
输入偏压只影响压力度数的显示，不影响电流输出Input bias voltage affects only pressure readings,  does not affect the current output

因灌油毛细管引起偏压bias voltage caused by capillary filling grease
显示偏压display bias voltage
同时按+Z及+S或同时按-Z及-S，两秒后显示恢复正常press + S and + Z At the same time or press- Z and the –s at the same time, two seconds later returned to normal

第十八页
偏压登陆bias voltage landing
按+Z及+S两次press +z and +S twice
清除偏压clear bias voltage
按-Z及-S两次press  and  twice
第十九页
标定Calibration
一般说明general description
量程零点和满度可以在传感器测量极限内任意设定，注意满度不能小于额定量程的5%
zero and full range can be set arbitrarily in sensor measurement, note full range cannot be less than the 5% of rated range
无显示的变送器标定No display transmitter calibration
使用压力标定器施加准确的标准压力Using pressure calibrator accurately sets standard pressure
如果所加标准压力不能和量程零点和满度恰好相等If the standard pressure is not exactly equal to zero and full point range
请按下式计算相关电流press calculate the related current according to the following formula
电流current
接近量程零点的满度或满度的标准压力Close to zero of the full range or full range standard pressure
零点压力zero point pressure
满度压力full point pressure
第二十页
无显示标定
无显示标定No display calibration
两种可能 Two Possibilities
标准压力恰与量程零点和满度相等Standard pressure just equals to zero and full range
施加准确的量程零点压力exert the accurate range zero pressure

例如for example
同时按press at the same time
结果results
施加准确的满度压力exert accurate full pressure
同时按press at the same time
结果results
标准压力接近量程零点和满度压力Standard pressure is close to zero and full range

调整满度adjust full point

施加标准压力exert standard pressure
例如for example
计算相应电流值calculate related current
例如，通过按+Z或-Z将其输入For example, enter it by pressing the + Z or Z
结果results
施加标准压力exert standard pressure
例如for example
计算两个标准压力之差的电流值，这里是Calculate current value between the two standard pressure , here is
满度full point
通过按压+S或-S设置电流输出By pressing  the +S or - S to set current output
调整零点adjust zero point
保持标准压力，假设零点已正确设置条件下计算这个压力的电流，通过按压+Z或-Z值，这里0bar为零点而0.9bar标准压力，量程的90%，设置电流输出
Maintain standard pressure, assuming zero point has been set up correctly to calculate current under the condition of the pressure, by pressing + Z or - Z , 0 bar here is  zero point and the standard  is 0.9 bar pressure, 90% of the range, set the output current
结束end
第二十一页
带显示标定calibration With display
两种可能two possibilities
标准压力恰与量程零点压力相等Standard pressure equals to  the range zero pressure
施加准确的量程零点压力，例如exert accurate range zero pressure, for example
例如for example
同时按press at the same time
结果results
施加准确的满度压力,例如exert Accurate full pressure, for example
同时按press at the same time
结果results
无标准压力no standard pressure
指定量程零点和满度压力Specifies the range zero and full pressure
按+z或-z直至显示出所期望的量程零点压力，例如press + z or -z until it shows the desired range zero pressure, for example

结果results
按+s或-S直至显示出所期望的量程满度压力，例如press + z or -z until it shows the desired range full pressure, for example
结果results
第二十二页
阻尼T damping t
当开关在0或8位置时，T也可用手操作或二次表来设定When the switch is at zero or 8 position, T can be set by hand operation or secondary tables
输入input
输出output
阻尼系数T越高，模拟信号受压力快速波动的影响越小The higher damping coefficient T, the less analog signal affected by the rapid fluctuations in pressure
第二十三页
输出功能output function
输入input
输出output
线性linearity
用于压力和液位测量Used for pressure and liquid level measurement
用于流量测量used  for flow rate measurement
设置T和输出功能sent t and output function
T可自由编程T can be  free programmed
固定阻尼T设定用于压力和液位测量（线性功能）Fixed damping T set is  used for pressure and liquid level measurement (linear function)

用于流量测量（方根功能）Used in flow measurement (root  function)
第二十四页
流量小于Qmax的8.9%时注意When the flow rate is less than 8.9% of Qmax, please pay attention
方根功能Root function
当测量值接近零点时方根函数会产生不必要的高放大倍数。因此，当测量值小于最大流速的8.9%时，方根函数自动转换为线性函数。这个测量值对应于标定差压满度的0.8%。连接零点与转换点的直线适用于压差小于0.8%的情况When measured values close to zero root function , it will create unnecessary high magnification as a result.  So when the measured value is less than 8.9% of the maximum velocity, square root function is automatically converted to linear function. The measured values correspond to 0.8 %the calibration full point. Connection between the zero point and the point of straight line is suitable for the pressure difference less than 0.8% of the time
按键锁定与解锁Key lock and unlock
按键操作禁止Key operation is prohibited
按键操作允许Key operation allows
LCD显示LCD display
第二十五页
贮存storage
贮存环境温度storage  temperature
贮存环境湿度storage humidity
运输transportation
产品在符合包装的条件下运输，在运输过程中防止雨淋，避免受强烈振动与碰撞
Products should be transported under the condition of packaging, preventing rain and avoiding strong vibration and impact

使用期限service life
在用户遵守使用要求、贮存、运输规定的条件下，自用户购进之日起，12个月内因产品质量问题，而不能正常工作时，本公司负责为用户免费修理，更换部件或整机
If users comply with the requirements of usage, storage and transportation conditions, since the purchasing date, within 12 months due to quality problems and can't normal work, the company is responsible for free repair , replacing parts or the whole machine

产品配套Product Support
产品附件accessories of product
电缆密封套cable gland
随机文件files with the machine
安装使用说明installments and operating instructions
安装使用说明书installments and operating instructions

标定证书Calibration certificate世联翻译公司完成PMD安装说明书英文翻译

Unitrans世联翻译公司在您身边,离您近的翻译公司,心贴心的专业服务,专业的全球语言翻译与信息解决方案供应商,专业翻译机构品牌。无论在本地,国内还是海外,我们的专业、星级体贴服务，为您的事业加速！世联翻译公司在北京、上海、深圳等国际交往城市设有翻译基地，业务覆盖全国城市。每天有近百万字节的信息和贸易通过世联走向全球！积累了大量政商用户数据，翻译人才库数据，多语种语料库大数据。世联品牌和服务品质已得到政务防务和国际组织、跨国公司和大中型企业等近万用户的认可。 专业翻译公司,北京翻译公司,上海翻译公司,英文翻译,日文翻译,韩语翻译,翻译公司排行榜,翻译公司收费价格表,翻译公司收费标准,翻译公司北京,翻译公司上海。
