智能压力变速器Intelligent pressure transmission
安装使用说明书Installation instructions
北京瑞普恩德斯豪斯仪表有限公司Beijing Endress+Hauser Ripenss Instrumentation Co.,Ltd
第二页
智能压力变速器安装使用说明书Intelligent pressure transmission installation instructions
智能压力变速器是德国E+H公司新近推向市场的智能型仪器
Intelligent pressure transmission is Germany E + H company newly brought to the market of intelligent instruments
PMC和PMP的区别在于PMC采用陶瓷传感器，而PMP采用扩散硅传感器
PMC and PMP differ in that PMC uses ceramic sensors and PMP uses diffusion silicon sensors
目录catalogue
技术数据technical data
负载特性load characteristic
普通型电气连接Normal electrical connections
本安型接线框图Intrinsically safe wiring diagram
隔爆型接线和安装应注意explosion proof type connection and installation should pay attention to
本安型安装使用时应注意Intrinsically safe type installation and using should pay attention to
安装方式installation method
安装后通过以下方法调整显示表的方向using the following method to adjust the direction of the display after installation

零点满度调节Zero and full adjustment
标定模式下的显示Calibration Mode display
按键设定零点Button to set zero point
按键设定满度Button to set full point
偏压bias voltage
标定Calibration
无显示标定No display calibration
带显示标定Display calibration
阻尼设定damping setting
贮存storage
运输transportation
使用期限service life
产品配套Product Support
第三页：
技术数据technical data
输出output
按用户需要叠加数据信号stack data signal according to user needs

协议agreement
温度影响temperature effect
零点或满度输出zero or full output
线性度linearity
含迁移后量程range including after change
量程比range ratio
迟滞lag
重复性repeatability
预热时间preheating time
响应时间response time
长期漂移long term drift
输出阻尼output damping
允许温度allowable temperature
环境温度environment temperature
普通型ordinary type
本安型Intrinsically safe type
隔爆型flame-proof type
介质温度medium temperature
防爆型explosion proof type
工作电压working voltage
振动影响vibration influence
下述情况无影响Had no effect on the following situation
第四页
振程vibration level
防护等级level of protection
防爆标志explosion-proof sign
本安型Intrinsically safe type
隔爆型flame-proof type
本安型应与以下四种安全栅中的任一种组成本安防爆系统
Intrinsically safe type should combine with either of the following four kinds of safety barrier to be safety explosion protection system
现场显示status display
LCD数字LCD Digital
棒图显示或指针式模拟显示（任选件）Bar graph display or pointer analog display(any one)

防爆型explosion proof type
普通型ordinary type

第五页
普通型电气连接Normal electrical connections
检测detection
本安型接线框图Intrinsically safe wiring diagram

安全栅Safety Barrier
危险区danger area
安全区safety area
本安型Intrinsically safe type
第六页
防爆型接线和安装应注意Explosion-proof wiring and installation should pay attention to
开盖前务必切断电源Be sure to cut off power supply before open
接线后或显示表调整方向后，应注意将盖旋紧再用盖侧的金属块通过螺钉压紧在盖的边沿上
After wiring or adjusting display direction, pay attention to tighten it and use metal block by screw clamps on the edge of the cove.
隔爆型电源电压Flameproof power supply voltage
隔爆型选用的电缆线外径，必须与密封圈内径相配Flameproof type’s cable diameter must be matched with the sealing ring inside diameter

变送器外壳设有接地端子，用户在安装使用时应可靠接地
Transmitter shell is equipped with grounding terminals. Should be reliable grounding when used in the installation
用户在安装使用和维护产品时应同时遵守GB50058-92和GB3836.15-2000的有关要求
Users shall comply with GB3836.15-2000 and GB50058-920 on request in the installation and maintenance of the products

电缆引入口应配用经防爆认可的Exd C等级的电缆引入装置
Cable introduce mouth should be equipped with Exd C level of the explosion-proof cable entry device

本安型安装使用时注意Intrinsically safe type should pay attention to when installation and using
变送器必须与安全栅配套使用构成本安防爆系统
Transmitter must be used with safety gate to compose intrinsically safe type explosion protection system

夲安系统的接线请同时参阅产品说明书和安全栅使用说明书
intrinsically safe type system wiring should refer to product specifications and safety barrier operation instruction at the same time
本安系统的布线应尽量避免外界电磁干扰的影响，并将电缆分布参数控制在0.06uf和1mH以内
Intrinsically safe type wiring should avoid the influence of outside electromagnetic interference as far as possible, and cable distribution parameters should be controlled within 0.06 uf and 1 mh
安全栅的安装、使用和维护应遵守安全栅使用说明书
Safety barrier installation operation and maintenance shall comply with the safety barrier operating instructions
用户在安装使用和维护产品时务必认真阅读产品安装使用说明书，并严格遵守和的有关要求要求
Please read the product installation instructions, and strictly comply with relevant requirements ofandin the installation operation and maintenance of this product
变送器外壳设有接地端子，用户在安装使用时应可靠接地
Transmitter shell is equipped with grounding terminals, should be reliable grounding when use in the installation

第七页
安装方式installation mode
直装式：通过螺纹或法兰连接件直接安装于工艺设备，测量精度和安装方向无关
direct-mounted  type:  installed directly on the process equipment  through the threaded or flanged fittings,  measurement precision has nothing to do with  installation direction

管架式：采用导管引压，用安装支架装于水平管架或垂直管架上（如图）
Pipe rack type: using catheter to bring pressure, installed in horizontal or vertical piping support with mounting bracket (as shown in the picture)

墙装：采用导管引压，用安装支架固定于墙面（如图）
Wall type: using the pipe to bring pressure, installed to the wall with mounting bracket. (as shown in the picture)

水平管架horizontal pipe rack
垂直管架vertical pipe rack

墙装 wall type
第八页
安装后可以通过以下方法调整显示表的方向
After installation, can use the following method to adjust the direction of the display

松开壳体上的螺钉，壳体可转动270度（注意调整后仍将螺钉旋紧）
Loosen the screw on the shell, rotating shell 270 degrees (note adjusted screw tightening)
打开显示窗盖，显示表可90度一级转动到所需位置
Open the display window cover, display table can be turned 90 degrees to the required position
向外推开卡头push the card head out
第九页
零点满度调节zero and full adjustment
压力与电流显示Pressure and current display
两个例子two examples
标定的测量量程Calibrated measuring range
相对压力relative pressure
绝对压力absolute pressure
第十页
标定模式下的显示display of the calibration mode
显示压力零点Display the zero pressure
显示压力满度Display the full pressure
传感器例sensor example
零点zero point
满度full point
量程range
显示display
传感器低限Sensor low limit
传感器高限Sensor high limit
在标定零点和满度期间，条形显示器示出的压力量程和传感器测量范围极限
Between the calibrated zero and full point, bar display shows the pressure range and sensor measurement range limit

反向电流输出Reverse current output
第十一页
按键设定零点Button to set zero point
零点显示zero point display
按+Z或-Z press  or
松开两秒后显示返回正常Loosen for two seconds,  display returns to normal
按键button
增加零点压力Increase the zero point pressure
按+Z两次之后保持至所需值After press the + Z button twice, keep to the required value
减少零点压力decrease the zero point pressure
按-Z两次之后保持至所需值After press the - Z button twice, keep to the required value
第十二页
按键设定满度Button to set full point
满度显示full point display
按+S或-S press or
松开两秒后显示恢复正常after Loosen for  two seconds,  the display returns to normal
按键press button
增加满度压力increase full point pressure
按+S两次后保持至所需值After press the + S button twice, keep to the required value

减少满度压力decrease the full point pressure

按-S两次之后保持至所需值After press the- Z button twice, keep to the required value

第十三页
偏压bias voltage
静压柱及方向效应的校正Hydrostatic column and direction effect correction
显示偏压exhibit bias voltage

同时按+Z及+S或同时按-Z及-S，两秒后显示恢复正常
press + S and + Z At the same time or press- Z and the –s at the same time, two seconds later returned to normal

偏压登陆bias voltage landing
按+Z及+S两次press +z and +S twice
清除偏压clear bias voltage
按-Z及-S两次press  and  twice
第十四页
标定Calibration
一般说明general description
量程零点和满度可以在传感器测量极限内任意设定，注意满度不能小于额定量程的5%
zero and full range can be set arbitrarily in sensor measurement, note full range cannot be less than the 5% of rated range
无显示的变送器标定No display transmitter calibration
使用压力标定器施加准确的标准压力Using pressure calibrator accurately sets standard pressure
如果所加标准压力不能和量程零点和满度恰好相等If the standard pressure is not exactly equal to zero and full point range
请按下式计算相关电流press calculate the related current according to the following formula
电流current
接近量程零点的满度或满度的标准压力Close to zero of the full range or full range standard pressure
零点压力zero point pressure
满度压力full point pressure
第十五页
无显示标定No display calibration
两种可能 Two Possibilities
标准压力恰与量程零点和满度相等Standard pressure just equals to zero and full range
施加准确的量程零点压力exert the accurate range zero pressure

例如for example
同时按press at the same time
结果results
施加准确的满度压力exert accurate full pressure
同时按press at the same time
结果results
标准压力接近量程零点和满度压力Standard pressure is close to zero and full range

施加标准压力exert standard pressure
例如for example
计算相应电流值calculate related current
例如，通过按+Z或-Z将其输入For example, enter it by pressing the + Z or Z
结果results
施加标准压力exert standard pressure
例如for example
计算相应电流值，例如，通过按+S或-S将其输入Calculated corresponding current value, for example, by pressing the +S or - S to enter it

结果results
第十六页
带显示标定calibration With display
两种可能two possibilities
标准压力恰与量程零点压力相等Standard pressure equals to  the range zero pressure
施加准确的量程零点压力，例如exert accurate range zero pressure, for example

同时按press at the same time
结果results
施加准确的满度压力,例如exert Accurate full pressure, for example
同时按press at the same time
结果results
无标准压力no standard pressure
指定量程零点和满度压力Specifies the range zero and full pressure
按+z或-z直至显示出所期望的量程零点压力，例如press + z or -z until it shows the desired range zero pressure, for example

结果results
按+s或-S直至显示出所期望的量程满度压力，例如press + z or -z until it shows the desired range full pressure, for example
结果results
第十七页
阻尼设定damping set
开关位于位置0时，t也可用手持终端或二次表（例如FMX770）来设定If Switch is located at position 0, t can also be set by hand terminal or secondary tables (for example FMX770)

输入input
输出output
缺省位置1 default location 1
固定阻尼设定Fixed damping Settings
不用don’t use
第十八页
贮存storage
贮存环境温度storage  temperature
贮存环境湿度storage humidity
运输transportation
产品在符合包装的条件下运输，在运输过程中防止雨淋，避免受强烈振动与碰撞
Products should be transported under the condition of packaging, preventing rain and avoiding strong vibration and impact

使用期限service life
在用户遵守使用要求、贮存、运输规定的条件下，自用户购进之日起，12个月内因产品质量问题，而不能正常工作时，本公司负责为用户免费修理，更换部件或整机
If users comply with the requirements of usage, storage and transportation conditions, since the purchasing date, within 12 months due to quality problems and can't normal work, the company is responsible for free repair , replacing parts or the whole machine

产品配套Product Support
产品附件accessories of product
电缆密封套cable gland
随机文件files with the machine
安装使用说明installments and operating instructions
安装使用说明书installments and operating instructions

标定证书Calibration certificate
第十九页
北京瑞普恩德斯豪斯仪表有限公司Beijing Endress+Hauser Ripenss Instrumentation Co.,Ltd
北京市朝阳区三元桥霞光里5号Sanyuanqiao  Xiaguangli No.5 Beijing Chaoyang District
电话Phone
传真Fax
